Measurements
Sprint 15 boat setup 13th August 2012
|
measurement is from halyard shackle pin to top of traveller track. |
|
|
|
|
↓↓↓ |
↓↓↓ |
|
forestay |
|
|
shroud pin |
feet/inches |
mm |
forestay |
|
|
boat no. |
hole from top |
|
|
pull |
inches |
Ian Bolton |
1698 |
3 |
22' 6.5" |
6870 |
|
12 |
Liam Thom |
554 |
3 |
22' 6.75" |
6877 |
|
12 |
Simon Giles |
1944 |
5 |
22' 6" |
6858 |
|
10 |
Bob Marks |
1960 |
3 |
22' 6.25" |
6864 |
|
11 |
Stuart Pierce |
1813 |
3 |
22' 6.25" |
6864 |
|
14 |
Christine Roman |
1925 |
3 |
22' 6.25" |
6864 |
|
12 |
Mark Pritchard |
1907 |
5 |
22' 6.25" |
6858 |
|
12 |
Chris Read |
642 |
3 |
22' 6.5" |
6870 |
|
11 |
Erling Holmberg |
2007 |
3 |
22' 5.5" |
6845 |
|
12 |
Phil Davis |
1990 |
5 |
22' 5.75" |
6850 |
|
10 |
Geoff Howlett |
1953 |
4 |
22' 5.75 |
6850 |
|
15 |
Keith Newnham |
1150 |
3 |
22' 6.75" |
6877 |
6.5 lbs |
9 |
Sean Strevens |
1779 |
2 |
22' 5.125" |
6835 |
|
15 |
Bob Baker |
1926 |
4 |
22' 5.5" |
6845 |
|
11 |
John Shenton |
1956 |
4 |
22' 4.5" |
6820 |
|
15 |
Stuart Dyer |
1739 |
3 |
22' 4.5" |
6820 |
|
16 |
Liam Thom |
1890 |
3 |
22' 4.25" |
6812 |
|
14 |
Sean Mckenna |
1728 |
5 |
22' 6" |
6857 |
|
13 |
Paul Grattage |
1458 |
6 |
22' 3.5" |
6795 |
|
22 |
Alan Howie-Wood |
1704 |
5 |
22' 6.75" |
6877 |
|
13 |

The measurement is taken from the shackle on the main halyard

to the traveler track on the back beam

The tension is from the furling gear to the base of the mast.
